RS232 Control
• Splitter Control: Connect the control PC to the
Splitter's Master RS232 port and install the software
• Receiver Control: Connect the control PC to the
Remote RS232 port and install the software
RS232 Control Software
Works with most serial command and monitoring
software such as CommWatch.
• Download CommWatch or any similar serial
command software
• Installation: Copy the control software files and
paste them to the hard drive of your PC
• Uninstallation: Delete all control software files
from the PC
Basic Settings
1. Connect all input and output devices as needed,
then connect the PC to the desired unit.
2. Double click the software icon to run the serial
control software. The icon is shown below.
The examples shown on this page and the following page
are from CommWatch serial command software.
