page no.
7
Assembly Instructions (continued)
13
Assemble Right Side Shelf
A
x 5
D
x 2
14
Attach Left Side Shelf Assembly
Note: Leave 5 mm of bolt threads exposed. Do not fully tighen until step 15.
D
x 2
15
Attach Right Side Shelf Assembly
Note: Leave 5 mm of bolt threads exposed. Do not fully tighen until step 15.
D
x 2
16
Secure Side Shelves
Note: Tighten screws from steps 14 and 15.
A
x 2
D
x 4
To Next Page
