GOLDONI UNO Series User Manual

41
Electric schematics legend: starting system and lights
(See last page)
1 Light switch
2 Generator warning light
3 Fuse 15A (take-offs)
4 Power socket
5 Generator
6 Battery charge regulator
7 Starter motor
8 Battery
6 TECHNICAL DETAILS
6.1 SPEED
SPEED CHART
In km/h - with engine at 3600 Rpm
(Values are indicative)
Inverter cultivating direction moving direction
Gears
Wheels
1st 2nd 3rd (1) 1st 2nd 3rd (1)
3.50-8" 1,3 2,5 1,5 3,1
4.00-8" 1,5 3,0 5,5 1,7 3,3 5,9 (2)
4.0-10" 1,7 3,5 6,2 1,9 3,8 6,8 (2)
16x6.50-8" 1,5 3,0 5,5 1,7 3,3 5,9 (2)
18x6.50-8" 1,7 3,5 6,2 1,9 3,8 6,8 (2)
5.0X10" (3) 1,5 3,0 5,5 2,1 4,3 7,8 (2)
(1) Models 3+3 only
(2) Speed impeded in reverse when in cultivating direction.
(3) Only for Bingo
6.2 OUTSIDE WHEEL WIDTH
OUTSIDE WHEEL WIDTH
(Values are indicative)
Wheels
Outside of wheel mm.
Single axle With differential
3.50-8" 410-460-520
4.00-8" 420-470-530 440
16x6.50-8" 560
18x6.50-8" 570
4.0-10" 450-500-560 500-590-650
5.0-10" 570 - 700

GOLDONI UNO Series Specifications

General

Brand	GOLDONI
Model	UNO Series
Category	Tiller
Language	English
