PRODUCT IDENTIFICATION
12
MB R 8 00 A A 1
DESIGN SERIES:
MB: Modular Blower
MOTOR TYPE:
R: Constant Speed
E: Variable Speed
AIRFLOW DELIVERED
08: 800 CFM
12: 1200 CFM
16: 1600 CFM
20: 2000 CFM
FACTORY HEAT
00: No Heat
ELECTRICAL SUPPLY:
1: 208-230V/60hZ/1 ph
CIRCUIT BREAKER
A: No Circuit Breaker
B: Circuit Breaker
DESIGN SERIES
A: First Series
C A P F 1824 A 6 A
PRODUCT
TYPE:
C: Indoor Coil
CABINET FINISH:
U: Unpainted
P: Painted
N: Unpainted Case
EXPANSION
DEVICE:
F: Flowrater
NOMINAL CAPACITY RANGE
@ 13 SEER
1824: 1 1/2 to 2 Tons
3030: 2 1/2 Tons
3636: 3 Tons
3642: 3 to 3 1/2 Tons
4860: 4 & 5 Tons
REVISION
A: Revision
NOMINAL WIDTH FOR GAS FURNACE
A: Fits 14" Furnace Cabinet
B: Fits 17 1/2" Furnace Cabinet
C: Fits 21" Furnace Cabinet
D: Fits 24 1/2" Furnace Cabinet
N: Does Not Apply (Horizontal Slab Coils)
APPLICATION
A: Upflow/Downflow Coil
H: Horizontal A Coil
S: Horizontal Slab Coil
REFRIGERANT
CHARGE:
6: R-410A or R-22
2: R-22
4: R-410a
