COOLING PERFORMANCE DATA
GSH130421A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSH130421A* / ARUF49-00*-1* / ARUF36421A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 5963677159636771596367715963 67 715963677159636771
MBh 40.6 41.5 44.3 47.3 39.6 40.5 43.3 46.2 38.7 39.5 42.2 45.1 37.7 38.6 41.2 44.0 35.9 36.6 39.1 41.8 33.2 33.9 36.3 38.8
S/T 0.95 0.90 0.73 0.54 1.00 0.93 0.76 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63
Delta T2120181422201814212018142121 18 142020181418181713
1688 KW 2.89 2.94 3.03 3.12 3.09 3.15 3.25 3.35 3.27 3.34 3.44 3.55 3.43 3.50 3.61 3.73 3.57 3.64 3.76 3.88 3.69 3.76 3.88 4.01
AMPS 10.7 11.0 11.4 11.8 11.6 11.9 12.3 12.7 12.6 12.9 13.3 13.8 13.5 13.8 14.3 14.8 14.3 14.7 15.2 15.8 15.2 15.6 16.1 16.7
HI PR 140 151 159 166 157 169 178 186 179 192 203 212 203 219 231 241 229 246 260 271 253 272 287 300
LO PR 62 65 71 76 65 69 75 80 68 72 78 84 71 75 82 88 74 79 86 92 77 82 89 95
MBh 39.4 40.2 43.0 46.0 38.5 39.3 42.0 44.9 37.6 38.4 41.0 43.8 36.6 37.4 40.0 42.8 34.8 35.6 38.0 40.6 32.2 32.9 35.2 37.6
S/T 0.91 0.85 0.70 0.52 0.94 0.89 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.80 0.60
Delta T2221181522211915222119152221 19 15 21 21 18 15 20 20 17 14
80 1500 KW 2.87 2.92 3.01 3.10 3.07 3.13 3.22 3.32 3.25 3.31 3.42 3.52 3.41 3.48 3.58 3.70 3.54 3.62 3.73 3.85 3.66 3.73 3.85 3.98
AMPS 10.7 10.9 11.3 11.7 11.5 11.8 12.2 12.6 12.5 12.8 13.2 13.7 13.4 13.7
14.1
14.7 14.2 14.6 15.0 15.6 15.1 15.4 15.9 16.5
HI PR 139 149 157 164 156 167 177 184 177 190 201 210 201 217
229
239 227 244 258 269 250 269 285 297
LO PR 61 65 71 75 64 68 75 80 67 71 78 83 70 75 82 87 74 78 85 91 76 81 88 94
MBh 36.4 37.1 39.7 42.4 35.5 36.3 38.8 41.4 34.7 35.4 37.8 40.5 33.8 34.6 36.9 39.5 32.1 32.8 35.1 37.5 29.8 30.4 32.5 34.7
S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.96 0.90 0.74 0.55 1.00 0.94 0.76 0.57 1.01 0.95 0.77 0.58
Delta T2221191523221915232219152322 19 152222191521201814
1313 KW 2.80 2.86 2.94 3.03 3.00 3.06 3.15 3.25 3.17 3.24 3.34 3.44 3.33 3.40 3.50 3.61 3.46 3.53 3.64 3.75 3.57 3.65 3.76 3.88
AMPS 10.4 10.6 11.0 11.4 11.2 11.5 11.8 12.3 12.2 12.4 12.9 13.3 13.0 13.3 13.7 14.3 13.8 14.2 14.6 15.2 14.6 15.0 15.5 16.1
HI PR 134 145 153 159 151 162 171 179 172 185 195 203 195 210 222 232 220 237 250 261 243 261 276 288
LO PR 59 63 69 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 74 79 86 91
MBh 41.3 42.1 44.1 47.0 40.3 41.1 43.0 45.9 39.4 40.1 42.0 44.8 38.4 39.1 41.0 43.7 36.5 37.2 38.9 41.5 33.8 34.4 36.1 38.5
S/T 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.99 0.81 1.00 1.00 1.00 0.81
Delta T2222211822222118212221182121 21 182020211818192017
1688 KW 2.91 2.96 3.05 3.14 3.12 3.18 3.27 3.37 3.30 3.37 3.47 3.58 3.46 3.53 3.64 3.76 3.60 3.67 3.79 3.91 3.72 3.79 3.91 4.04
AMPS 10.8 11.1 11.5 11.9 11.7 12.0 12.4 12.9 12.7 13.0 13.5 14.0 13.6 13.9 14.4 14.9 14.5 14.8 15.3 15.9 15.3 15.7 16.2 16.9
HI PR 141 152 161 168 159 171 180 188 180 194 205 214 205 221 234 244 231 249 263 274 255 275 290 303
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 40.1 40.9 42.8 45.6 39.1 39.9 41.8 44.6 38.2 39.0 40.8 43.5 37.3 38.0 39.8 42.5 35.4 36.1 37.8 40.3 32.8 33.4 35.0 37.4
S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77
Delta T2323221924232219232322192323 22 192222221920202018
85 1500 KW 2.89 2.94 3.03 3.12 3.09 3.15 3.25 3.35 3.27 3.34 3.44 3.55 3.43 3.50 3.61 3.73 3.57 3.64 3.76 3.88 3.69 3.76 3.88 4.01
AMPS 10.7 11.0 11.4 11.8 11.6 11.9 12.3 12.7 12.6 12.9 13.3 13.8 13.5 13.8 14.3 14.8 14.3 14.7 15.2 15.8 15.2 15.6 16.1 16.7
HI PR 140 151 159 166 157 169 178 186 179 192 203 212 203 219 231 241 229 246 260 271 253 272 287 300
LO PR 62 65 71 76 65 69 75 80 68 72 78 84 71 75 82 88 74 79 86 92 77 82 89 95
MBh 37.037.739.542.136.136.838.641.235.336.037.740.234.435.1 36.7 39.232.733.334.937.230.330.932.334.5
S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75
Delta T2423221924242219242422192424 23 202323221921222118
1313 KW 2.82 2.88 2.96 3.05 3.02 3.08 3.17 3.27 3.20 3.26 3.36 3.47 3.35 3.42 3.53 3.64 3.49 3.56 3.67 3.78 3.60 3.67 3.79 3.91
AMPS 10.5 10.7 11.1 11.5 11.3 11.6 11.9 12.4 12.3 12.6 13.0 13.5 13.1 13.4 13.9 14.4 13.9 14.3 14.8 15.3 14.8 15.1 15.6 16.2
HI PR 136 146 154 161 152 164 173 181 173 186 197 205 197 212 224 234 222 239 252 263 245 264 279 291
LO PR 60 63 69 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 79 87 92
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
