COOLING PERFORMANCE DATA

GSH130191A*

EXPANDED PERFORMANCE DATA

COOLING OPERATION

MODEL: GSH130191A* / AWB24-XX / AWUF18XX1A*

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

Airflow 596367715963677159636771596367715963677159636771

MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -

S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.86 0.71 0.50 - 0.86 0.72 0.50 -

Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

675 KW 1.25 1.27 1.31 - 1.33 1.36 1.40 - 1.41 1.44 1.48 - 1.47 1.50 1.55 - 1.53 1.56 1.61 - 1.58 1.61 1.66 -

AMPS 4.0 4.1 4.2 - 4.3 4.4 4.5 - 4.6 4.7 4.9 - 4.9 5.0 5.2 - 5.2 5.3 5.4 - 5.4 5.6 5.7 -

HI PR 136 146 155 - 153 164 173 - 174 187 197 - 198 213 225 - 222 239 253 - 246 264 279 -

LO PR 61 65 71 - 65 69 75 - 67 71 78 - 70 75 82 - 74 79 86 - 76 81 89 -

MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -

S/T 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -

Delta T 19 16 12 - 19 16 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -

70 600 KW 1.24 1.26 1.30 - 1.32 1.35 1.39 - 1.40 1.43 1.47 - 1.46 1.49 1.54 - 1.52 1.55 1.60 - 1.57 1.60 1.65 -

AMPS 4.0 4.1 4.2 - 4.3 4.4 4.5 - 4.6 4.7 4.8 - 4.9 5.0 5.1 - 5.1 5.2 5.4 - 5.4 5.5 5.7 -

HI PR 135 145 153 - 151 163 172 - 172 185 195 - 196 211 222 - 220 237 250 - 243 262 277 -

LO PR 61 64 70 - 64 68 74 - 66 71 77 - 70 74 81 - 73 78 85 - 76 80 88 -

MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -

S/T 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.73 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.79 0.66 0.46 -

DT 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -

525 KW 1.22 1.24 1.27 - 1.30 1.32 1.36 - 1.37 1.39 1.43 - 1.43 1.46 1.50 - 1.48 1.51 1.56 - 1.53 1.56 1.61 -

AMPS 3.9 4.0 4.1 - 4.2 4.3 4.4 - 4.5 4.6 4.7 - 4.7 4.8 5.0 - 5.0 5.1 5.3 - 5.3 5.4 5.5 -

HI PR 131 141 148 - 147 158 167 - 167 179 189 - 190 204 216 - 214 230 243 - 236 254 268 -

LO PR 59 62 68 - 62 66 72 - 64 69 75 - 68 72 79 - 71 75 82 - 73 78 85 -

MBh 17.94 18.47 19.99 21.45 17.52 18.04 19.53 20.96 17.10 17.61 19.06 20.46 16.69 17.18 18.60 19.96 15.85 16.32 17.67 18.96 14.68 15.12 16.36 17.56

S/T 0.85 0.76 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.61 0.40 0.94 0.84 0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.66 0.43

Delta T21 191611211916 11 21191611212016112119161120181510

675 KW 1.26 1.28 1.32 1.36 1.34 1.37 1.41 1.45 1.42 1.45 1.49 1.53 1.49 1.52 1.56 1.61 1.54 1.57 1.62 1.67 1.59 1.62 1.67 1.72

AMPS 4.1 4.1 4.3 4.4 4.3 4.4 4.6 4.7 4.7 4.8 4.9 5.1 4.9 5.0 5.2 5.4 5.2 5.3 5.5 5.7 5.5 5.6 5.8 6.0

HI PR 137 148 156 163 154 166 175 183 175 189 199 208 200 215 227 237 225 242 255 266 248 267 282 294

LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 95

MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2

16.7

18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1

S/T 0.82 0.73 0.55 0.35 0.84 0.76 0.57 0.37 0.87 0.77 0.59 0.38 0.89

0.80

0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41

Delta T2220161122201711222017112220 17 12 22 20 17 11 20 19 15 11

75 600 KW 1.25 1.27 1.31 1.35 1.33 1.36 1.40 1.44 1.41 1.44 1.48 1.52 1.47 1.50 1.55 1.60 1.53 1.56 1.61 1.66 1.58 1.61 1.66 1.71

AMPS 4.0 4.1 4.2 4.4 4.3 4.4 4.5 4.7 4.6 4.7 4.9 5.0 4.9 5.0 5.2 5.3 5.2 5.3 5.4 5.6 5.5 5.6 5.7 5.9

HI PR 136 146 155 161 153 164 173 181 174 187 197 206 198 213 225 234 222 239 253 264 246 265 279 291

LO PR 61 65 71 76 65 69 75 80 67 71 78 83 71 75 82 87 74 79 86 91 76 81 89 95

MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.40 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7

S/T 0.79 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.89 0.80 0.61 0.39 0.90 0.81 0.61 0.39

Delta T22 201712222117 12 22211712232117122220171221191611

525 KW 1.22 1.25 1.28 1.32 1.31 1.33 1.37 1.41 1.38 1.40 1.45 1.49 1.44 1.47 1.51 1.56 1.50 1.53 1.57 1.62 1.54 1.57 1.62 1.67

AMPS 3.9 4.0 4.1 4.3 4.2 4.3 4.4 4.5 4.5 4.6 4.7 4.9 4.8 4.9 5.0 5.2 5.0 5.2 5.3 5.5 5.3 5.4 5.6 5.8

HI PR 132 142 150 156 148 159 168 176 168 181 191 200 192 206 218 227 216 232 245 256 238 257 271 283

LO PR 59 63 69 73 63 67 73 77 65 69 76 81 68 73 79 85 72 76 83 89 74 79 86 92

Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system powe

AMPS=outdoor unit amps (comp.+fan)

High and low pressures are measured at the liquid and suction service valves.
