6
HEAT PUMP SPECIFICATIONS GSH130[18-60]*A*
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
May use fuses or HACR-type circuit breakers of the same size as noted.
GSH 3-PHASE
(1)
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: May use fuses or HACR type Circuit Breakers of the same size as noted.
GSH130[18-60]1
GSH130363A*
GSH130483A*
GSH130603A*
GSH130484A*
GSH130604A*
Cooling Capacity, BTUH 35,000 45,000 55,500 45,000 55,500
Compressor
R.L. Amps 9.0 12.4 17.3 5.8 6.7
L.R. Amps 65.5 88.0 123.0 44.0 49.5
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1/4 1/4 1/6 1/4 1/6
F.L. Amps 1.6 1.6 1.1 0.8 1.1
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 7/8" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 188 223 233 223 233
Design Subcooling Cooling (°F) 9 +
39 + 39 + 39 + 39 + 3
Power Supply 208/230-60-3 208/230-60-3 208/230-60-3 460/60/3 460/60/3
Minimum Circuit Ampacity
(1)
12.0 17.2 22.7 8.0 9.0
Maximum Overcurrent Device
(2)
20 20 40 15 15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 207 225 266 225 266
GSH130181A*
GSH130191A*
GSH130241A*
GSH130251A*
GSH130301A*
GSH130311A*
GSH130361A*
GSH130421A*
GSH130481A*
Cooling Capacity, BTUH 18,000 18,000 23,000 23,000 28,000 28,000 35,000 40,000 45,000
Compressor
R.L. Amps 6.2 9.0 9.2 10.9 10.8 12.2 8.3 16.5 17.9
L.R. Amps 34 41 43 54 60 63 48 95 104
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/6 1/6 1/6 1/4 1/4 1/4
F.L. Amps 1.51.51.51.51.51.51.61.61.6
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 7/8" 7/8" 7/8"
Refrigerant Charge 127 115 106 117 153 153 188 213 223
Design Subcooling Cooling (°F) 9 +
39 + 39 + 39 + 39 + 39 + 39 + 39 + 39 + 3
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
9.3 12.7 13 15.1 15 16.7 16.9 22.3 27.8
Maximum Overcurrent Device
(2)
15 20 20 20 20 20 20 30 40
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 193 193 198 207 199 199 207 219 225
GSH130601A*
55,500
25.0
148
7 PSIG/25 PSIG
1/6
1.1
3/8"
7/8"
233
9 +
3
208/230-60-1
32.3
50
1/2 or 3/4
266
