03 Product Introduction
User Manual V1.0-2023-05-20
Usable energy description
9.6kWh
(LX F9.6-H-20)
12.8kWh
(LX F12.8-H-20)
16.0kWh
(LX F16.0-H-20)
Power control unit
Power control unit
Power control unit
Battery 1
Battery 2
Battery 2
Battery 2
Battery 3 Battery 3
Battery 4
Battery 4
Battery 5
Battery 3
Battery 1
Battery 1
22.4kWh
(LX F22.4-H-20)
25.6kWh
(LX F25.6-H-20)
28.8kWh
(LX F28.8-H-20)
19.2kWh
(LX F19.2-H-20)
Power control unit
Power control unit
Power control unit
Power control unit
Battery 1
Battery 2
Battery 2
Battery 2
Battery 2
Battery 3
Battery 3
Battery 4
Battery 4
Battery 5
Battery 6
Battery 6
Battery 6
Battery 7
Battery 7
Battery 7
Battery 8
Battery 8
Battery 9
Battery 5 Battery 5
Battery 5
Battery 6
Battery 4
Battery 4
Battery 3
Battery 3
Battery 1
Battery 1
Battery 1
NOTICE
• The battery system supports capacity expansion. A maximum of nine battery modules
can be used to extend the usable energy of the battery system. Expand the battery system
capacity in strict compliance with the expansion requirements. Contact the dealer or
manufacturer for more details. Failure to follow the requirements may result in an under-
voltage, over-voltage or voltage dierence fault in the battery system.
• Actual height varies slightly. Refer to the actual installation height.
To Next Page
