Google Nest Protect Guide

2019 | Condential and Proprietary | Do not distribute
Weight Siren Operating temperature Lights
Sensors
● 40˚F to 100˚F
● (4˚C to 38˚C)
● Humidity: 20%RH to
80%RH
Ambient light
RGB light ring
with 6 LEDs
Audio
Speaker loudness: 80
dB @ 3  (1 m) @ 1kHz
85 dB SPL @ 10  (3 m)Baery: 13.9 oz
(379.0 g
Wired: 13.2 oz
(375.0 g))
Wireless
● 802.11b/g/n (2.4GHz) Wi-Fi
● 802.15.4 (2.4GHz)
● Bluetooth Low Energy
Product requirements
● Wi-Fi connection
● Phone or tablet with Andriod 5.0 or later and iOS 10 or later. Check detailed Nest app requirements here.
●
● Free Nest account
Sensors
● Split‑Spectrum smoke sensor
● Occupancy (120° eld of view up to 20 feet)
● 10 year electrochemical carbon monoxide sensor
● Ambient light
● Temperature
● Accelerometer
● Humidity
● Microphone
Power requirements
● Baery model: Six long-life AA baeries (Energizer® Ultimate Lithium “L91”)
● Wired model: Three long-life backup AA baeries (Energizer® Ultimate Lithium “L91”)
● Protect requires full line voltage and is not compatible with low voltage wiring.
All the specs

Google Nest Protect Specifications

General

LED color	Red / Green / Blue
Detector type	Carbon monoxide detector
Maximum range	15 m
Mounting type	Surface-mounted
Product color	White
Speaker power	2 W
Alarm decibels	85 dB
Number of LEDs	6
Housing material	Plastic
Languages support	Italian
Placement supported	Horizontal/Vertical
Wireless connection	Yes
Number of simultaneously connected devices (max)	18
Package type	Box
Quantity per pack	1 pc(s)
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Connectivity technology	Wireless
Number of screws	4
Power source	Battery
Battery voltage	1.5 V
Battery technology	Lithium
Compatible battery sizes	AA
Operating temperature (T-T)	4 - 38 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	38.5 mm
Width	135 mm
Weight	379 g
