Google Nest Protect User Guide

Breaker box
WARNING
ELECTRICAL SHOCK HAZARD
Failure to turn o the power may result in serious
electrical shock, injury and death.
9
English
5. Turn o power
Protect yourself and avoid blowing a fuse. Switch o
the correct circuit breaker for the room where you
are installing Nest Protect or remove the fuse from
the fuse box.
4. Test before you install
Once you’re done seing up all of your Nest Protects,
make sure they’ve been added to your account.
Push the buon on one Nest Protect and follow the
instructions. All of your Nest Protects should speak
up. Now you can install them on the ceiling or wall.
Tip: To double check Nest Protect’s room name, press
the buon once. You’ll hear the location that you
assigned to it during setup. It’ll say something like,
“Ready in the bedroom.”

Google Nest Protect Specifications

General

LED color	Red / Green / Blue
Detector type	Carbon monoxide detector
Maximum range	15 m
Mounting type	Surface-mounted
Product color	White
Speaker power	2 W
Alarm decibels	85 dB
Number of LEDs	6
Housing material	Plastic
Languages support	Italian
Placement supported	Horizontal/Vertical
Wireless connection	Yes
Number of simultaneously connected devices (max)	18
Package type	Box
Quantity per pack	1 pc(s)
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Connectivity technology	Wireless
Number of screws	4
Power source	Battery
Battery voltage	1.5 V
Battery technology	Lithium
Compatible battery sizes	AA
Operating temperature (T-T)	4 - 38 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	38.5 mm
Width	135 mm
Weight	379 g
