Gooxi RMC4124-670-HS User Manual

Shenzhen Gooxi Hengyu Technology Co., Ltd
Chapter 3 Chassis Parameters
Basic Parameters
Chassis style
Rack mount
Chassis structure
4U
Applicable motherboard
EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX
Supported motherboard brands
Gooxi、Intel、ASUS、SuperMicro、TYAN、MSI、GIGABYTE,etc.
Power type
Single charge and 1+1 redundant power
Number of supported power
supplies
1
SGPIO
Support
Backplane
12Gb/s SASE expander backplane
Supported hot-swappable hard
drives
Supportive, compatible with SAS and SATA drives
Supported hot-swappable hard
fans
Support
Hard driver site
Twenty-four 3.5-inch (or 2.5-inch) hot-swappable hard disk sites; two 2.5
inch built-in non-hot-swappable hard disk sites, and two 2.5-inch rear-built
hot-swappable expandable sites (optional)
CD driver site
None
Hard disk shockproof system
Hard disk bracket is designed with EMI shrapnel. The unique shockproof
fan design can reduce the resonance between the fan and hard disk without
affecting the reading and writing speed of hard disks.
Cooling system
12038 fans of three brands are standard configuration
Windshield
Support
Intelligent control of temperature
7 half-height PCI or PCI-E expansion card sites
Expanded card site
Optional
Apparent Parameters
Front panel interface
1 on-off key, 1 restart key, 1 fan alarm lamp, 1 hard disk indicator and 2
network indicators
Free screws dismantle
Support
Fixed mode of cabinet
Ordinary
Configuration Parameters
Product material
Imported SGCC (galvanized steel sheet), ABS panel and punching net
Chassis dimension
670*444*177mm(Depth * width * height)
Chassis weight
19kg
Package dimension
902*591*318mm(Depth * width * height）
