Gooxi SL201 User Manual

25
No.
Name
J28,J30,J33,J34,J35,J37,J39,J42
Connectors 1, 2, 3, 4, 5, 6, 7, 8 for 4U system fans
in sequence
J26,J31,J35,J37,J39,J41
Connectors 1, 2, 3, 4, 5, 6 for 2U system fans in
sequence
J28,J30,J33,J35,J37,J39,J41
Connectors 1, 2, 3, 4, 5, 6, 7 for 1U system fans in
sequence
J59,J61,J62
3 sets of 2x6Pin hard drive backplane power
connectors
J55,J56
2 power supply connectors
J65,J70,J96,J97
4 sets of 2x8Pin high-power GPU connectors
J66,J67
2 rear window RISER backplane power connectors
J57,J63,J64
3 rear window hard drive (2 drives) backplane power
connectors
J73
NIC AUX power connector
JIIC_1,JIIC_2,JIIC_3,JIIC_5
2 hard drive backplane I2C connectors, 2 MCIO I2C
connectors
J3
PCH hardware strapping jumper
J52
CPU0 CPU1 socket present jumper
J45
CPLD debug jumper
J95
BIOS Recovery & ME Update jumper
J92
Chassis intrusion connector
J18
IPMB I2C connector
J19
VR upgrade programming I2C connector
J49
CPLD programming connector
J2
RAID KEY connector
J10
SATA port 0~3 connector
J8
SATA port 12~15 connector
J7
SATA port 16~19 connector
J15
Left Front panel connector
J13
Right Front Panel USB3.0 connector
J74
Right Front Panel VGA connector
J72
UUID board cable connector
J11
SATA Port8 M.2 connector
J12
SATA Port9 M.2 connector
CPU0
DIMMA1/A0/B1/B0/C1/C0/D1/D0
CPU0 DDR5 memory channel 1,2,3,4 connector
CPU0
DIMMH0/H1/G0/G1/F0/F1/E0/E1
CPU0 DDR5 memory channel 8,7,6,5 connector
CPU1
DIMMA1/A0/B1/B0/C1/C0/D1/D0
CPU1 DDR5 memory channel 1,2,3,4 connector
CPU1
DIMMH0/H1/G0/G1/F0/F1/E0/E1
CPU1 DDR5 memory channel 8,7,6,5 connector
