9. Camera Tilt Wheel
10. Ambient Light Sensor
11. Speaker
12. Controller Screen
13. Shutter Button [
]
1. Propellers
2. Power Button [
]
3. Orientation Lights
4. Camera Stabilizer
5. Battery Status Lights
6. Battery Status Button
7. Start/Stop Button
8. Land Button [
]
GETTING STARTED GETTING STARTED
2
3
6
5
7
8
9
12
11
13 15
14
16
10
17
14. Joysticks
15. Mode/Tag Button
16. Charging Port
17. Lanyard Tether Point
DRONE + BATTERY CONTROLLER + BATTERY CHARGER
1
4
CHANGE TO
H5 HARNESS
