28 308441
Parts
Fluid Section Parts List (Matrix Column 3)
Digit
Ref.
No.
Part No. Description Qty
3 101 15A615 COVER, fluid; aluminum 2
102 189402 MANIFOLD, inlet;
aluminum
1
103 15A616 MANIFOLD, outlet;
aluminum
1
104 15K448 PLATE, air side;
aluminum
2
105 189843 PLATE, fluid side;
carbon steel
2
106 115644 SCREW; M10 x 1.25;
35 mm (1.38 in.)
24
107 189410 BOLT; M12 x 1.75;
55 mm (2.17 in.); 316 sst
2
108* 104319 O-RING; PTFE 2
110 188970 LABEL, warning 1
111 102656 MUFFLER (not used on
Model No. 253485)
1
112 115645 SCREW; M10 x 1.50;
90 mm (3.54 in.)
4
4 101 194169 COVER, fluid; sst 2
102 194170 MANIFOLD, inlet; sst 1
103 194221 MANIFOLD, outlet; sst 1
104 15K448 PLATE, air side;
aluminum
2
105 189309 PLATE, fluid side; sst 2
106 112416 SCREW; M10 x 1.25;
30 mm (1.18 in.); sst
24
107 189410 BOLT; M12 x 1.75;
55 mm (2.17 in.); 316 sst
2
108* 104319 O-RING; PTFE 2
110 188621 LABEL, warning 1
111 102656 MUFFLER 1
112 112417 SCREW; M10 x 1.50;
90 mm (3.54 in.); sst
4
Digit
Ref.
No.
Part No. Description Qty
C 101 15A615 COVER, fluid; aluminum 2
102 192078 MANIFOLD, inlet;
aluminum; BSPT
1
103 15A658 MANIFOLD, outlet;
aluminum; BSPT
1
104 15K448 PLATE, air side;
aluminum
2
105 189843 PLATE, fluid side;
carbon steel
2
106 115644 SCREW; M10 x 1.25;
35 mm (1.38 in.)
24
107 189410 BOLT; M12 x 1.75;
55 mm (2.17 in.); 316 sst
2
108* 104319 O-RING; PTFE 2
110 188970 LABEL, warning 1
111 102656 MUFFLER 1
112 115645 SCREW; M10 x 1.50;
90 mm (3.54 in.)
4
D 101 194169 COVER, fluid; sst 2
102 195574 MANIFOLD, inlet; sst;
BSPT
1
103 195575 MANIFOLD, outlet; sst;
BSPT
1
104 15K448 PLATE, air side;
aluminum
2
105 189309 PLATE, fluid side; sst 2
106 112416 SCREW; M10 x 1.25;
30 mm (1.18 in.); sst
24
107 189410 BOLT; M12 x 1.75;
55 mm (2.17 in.); 316 sst
2
108* 104319 O-RING; PTFE 2
110 188621 LABEL, warning 1
111 102656 MUFFLER 1
112 112417 SCREW; M10 x 1.50;
90 mm (3.54 in.); sst
4
113 114862 NUT, hex, M10, fhn 8
