Motor/Air
Compressor
Cylinder Valve
Coil
15D560
N/O Main
Pow
er Switch
117693
N/C Pr
imer Switch 119064
Open in
Prime
Mode
The Switch will remain closed
until
air flow is present. The
Gun being triggered or a Air
Leak
will cause the ball to lift up
and open the circuit.
Main
Valve Coil
287326
N/C Air Flow
Sensor Switch
287326
15D559
Valve
asse
mbly
120V
Load Blk Neutral Wht
M
Grnd
Air Flow
Air Flow
Air
Co
mpressor
Coil
45psi
Exhausted
Air
Exhaus
ted
Air
Air Cooler
Exhausted
Air
Air
Regu
lator
Air
Coil
Cylinder V
alve 15D560:
With Coil Voltage Applied. This will allow
air to be exhausted and
the weight of the
motor
to push the cylinder rod in and remove
tens
ion on the Roto Flex Hose.
15D559
Valve
assembly
Gun Valve
RTX 1500 Electrical and Air Ladder Diagram
Power
cord plugged in and Power Switch ON and Gun Trigger Closed
KEY
Air Flow
Electrical Switching Circuit
Sensor Switch
To Next Page
