50
Headrest Support
Style A. To remove, pull out the pillow out.
Style B. To remove, unhook the elastic
strap that goes through the harness slots
and remove as shown.
Cup Holder
Cup holder can be on either side.
To attach, pull back the seat pad to
expose the attachment guide (1). Slide
the cup holder down the guide until it
locks into place (2).
To remove, place both hands under the
cup holder and push up on the cup holder
(3).
1
2
3
Style A
Style B
Style B
