7
This car seat is for children: Forward-Facing: 22-65 lb (10-30 kg)
Booster: 30-120 lb (14-54 kg)
1. Lay child restraint flat on back
Grab seat pad fabric in sitting area to
expose the gutters.
Make Sure all hands, fingers and other
objects are clear of the gutters.
2. Attach Harness Straps
Make Sure the harness straps are securely
attached within the “T”-shaped slots around
the arms as shown.
Harness
Strap
T-Slot
Arm
continue next page
Attach Head Support
Squeeze height adjust button and push head
support into slots on the back support as
shown. Head support will click into the back
support.
You may need to unfasten the hook and
loop attachment tape on both sides at the
top of the back support to allow for easier
access to the slots.
Always use child restraint with head
support installed and properly adjusted.
To Next Page
