Graco NOAH - Page 15

ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE /
INSTRUCCIONES DE ENSAMBLAJE
15
7
- Insert S & L into Q
- Insert I (X2) into G
- Insert P & M into J
- Tighten right 5 little more than half turn
to lock them together
correct/
correcto
incorrect/
incorrecto
5
LOCK
Q
G
S
L
P
M
7x
I
I
J
2
4
