Graco NOAH - Page 18

ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE /
INSTRUCCIONES DE ENSAMBLAJE
18
10
- Make sure the unit is level (squared).
- In beginning by the corners,
nail O to G, H, S& L with 13(x16)
x20
Required/Requis/Requerido
13
13
13
Pivot Line
Pivot Line
Pivot Line
