Graco NOAH User Manual

9
HARDWARE/ Quincailleries/ HERRAJE
Identifying the parts / Identification des pièces / Identificación de piez
1 X9
PH8X1-1/2”
Screw / Vis / Tornillo
9CR X3
Right Drawer
Runner
13 X20
Nail
14 X1
L-Bracket
18 X4
10CL X3
Left Drawer
Runner
11D R X3
Right C/board
Runner
12DL X3
Left C/board
Runner
5 X39
2 X57
M8 X 30mm
Wood Dowel/
Cheville en Bois/
Pasador de Madera
6 X44
M3. 5 X 16mm
Screw / Vis / Tornillo
7 X6
25mm MS
Knob Screw/
Vis de Bouton/
Tornillo para Perilla
8 X6
38mm Knob
Bouton
Perilla
3 X1
M4 Allen Key/
Liave Allen/
Clef Allen
4 X39
19 X5
M4 X 38mm
Screw / Vis / Tornillo
17 x 1
WALL STUD
Montant Du Mur
Montaje Para Pared
Camlock
Raccord camlock
Camlock
Camlock Bolt
Boulon Camlock
Tornillo Camlock

Graco NOAH Specifications

General

Brand	Graco
Model	NOAH
Category	Indoor Furnishing
Language	English
