Graco SnugRide Click Connect 35 User Manual

31
7. NEVER put two LATCH connectors on one
vehicle LATCH anchor

.
8. Test infant restraint for secure installation as
described in infant restraint “Final Safety
Check” page 42.
9. Check that the LATCH stays tight and does not
slip from the tightened position. If it does not stay
tight, try another seating position or contact
Graco at 1-800-345-4109.
10. To remove LATCH, push button while
pulling on the LATCH belt as shown

.
11. Press and hold LATCH release hinge

.
12. Push connector in, lift connector up and
pull out (away from anchor point)

.
13. Repeat steps 11 and 12 for other connector.





Graco SnugRide Click Connect 35 Specifications

General

Type	Infant Car Seat
Child Weight Capacity	4-35 lbs
Weight Limit	35 lbs
Removable Seat Cover	Yes
Height Limit	32 inches
Compatibility	Graco Click Connect Strollers
Safety Features	EPS Energy Absorbing Foam
Canopy	Adjustable
