6
3. Seat Pad
Wrap seat pad around front of base and attach with
elastic straps as shown.
4. Back Support Pad
On certain models, your lower back support
pad may not be attached to the back support.
Place lower back support pad around edges of
support as shown. Then fasten lower elastic
strap to the metal hook on the other side of the
seat pad.
If your lower back support pad is already
attached go to step 5.
5. Head Support
Squeeze adjustment button and slide two
pieces together until they snap into place.
CHECK to make sure two pieces are securely
snapped together by pulling on them.
2. Cupholder
CUPHOLDER MUST BE INSTALLED.
Remove cupholder from compartment in bottom of base.
Align tabs on side and bottom of
cupholder with their slots in base and
press cupholder into place.
DO NOT REMOVE CUPHOLDER ONCE IT IS ATTACHED.
