130
Locking Latchplate and ELR Retractor
A latchplate that holds the lap belt snug after it has been
adjusted; contains a metal bar on the underside of the
hardware that “locks” the belt in position.
When installing the car seat, route the vehicle seat belt
through the proper belt path and buckle it in. Then, pull
upwards on the shoulder belt so that the lap belt gets
tight around the car seat.
Grab the sides of the seat at the belt path and slide the
seat side-to-side and front-to-back. The seat should not
move more than 1” (2.5 cm).
Note: When using the lock-off, you are not required to
switch the retractor as an installation step. The lock-off
locks the seat belt. However, it is recommended to
switch the retractor after the installation is complete to
avoid a possible strangulation risk.
• When using the SnugLock
®
lock-off, route the vehicle
seat belt into the proper belt path under the lock-off
and buckle. Push down firmly on the center of the
seat while pulling on the shoulder belt to remove the
slack. Do not pull on the strap with excessive force.
Close the SnugLock
®
lock-off. Test for tightness.
Slowly pull the shoulder belt all the way out to switch
it to locking mode.
