If this stove/appliance is not properly installed in a house, there is a risk of fire. For your
safety, follow the installation directions. Contact local building or fire officials about
restrictions and installation inspection requirements specific to your area.
UNPACKING
* Installations should use two people, as the unit is heavy.
1- Remove the protective plastic wrapping from the unit.
2- Inspect the unit for any obvious physical damage.
3- Remove the 2 Screws holding down the unit to the pallet (if mounted to a pallet)
4- Or remove the Steel Tabs bolted to the bottom of the stove. (If mounted to a pallet)
5- Open Hopper, release the Hold Down Latch, and remove the Hopper Lid.
6- Remove and inspect the contents of the hopper (use checklist below).
7- Attach the Cast Iron Legs using the bolts provided.
8- Open the stove door and ensure that the Firebox is present and is centered on the
Removable Washer.
9- Close and lock the stove door making sure the latch is tight and locks with a reasonable
amount of force.
CHECKLIST
IN THE HOPPER: VENTING KIT:
Qty 1 - set of 4 Cast Iron Legs Qty 1 - Stainless Steel Vent / Wall Flange
Qty 1 – Stainless Steel Poker Qty 1 - Length of 36” Exhaust Pipe
Qty 1 – Copy of Grain Stove Manual Qty 1 - 5” to 6” Galvanized Adapter
Qty 1 – Wood Pellet Scraper Attachment
*Should there be any items missing, first check with your Dealer that you purchased the
unit from. Or call us at Grain Stoves Inc.
VENT KIT
5
