7 Inspection of the belt buckle with belt buckle cable
Preconditions for fault diagnosis:
• The electrical system of the vehicle has been inspected and found to be OK in compliance with the vehicle operating
instructions.
• The belt buckle is open (belt latch is not locked into the belt buckle).
Note: The components mentioned above are illustrated in Chapter 2.1, if not stated otherwise in this text.
Step
no.
Inspect/operate Result/specified status Troubleshooting
7.1 • Disconnect the electrical connection (F)
between the belt buckle cable and the cable of
the belt buckle contact.
• Measure the resistance at the pins P1 and P2
in the plug of the belt buckle cable.
P1 Ω P2
= 0.2 Ω (± 10%)
>> 0.2 Ω (→ ∞) (interruption)
<< 0.2 Ω (→ 0) (short-circuit)
End of inspection.
Replace the belt buckle and
the belt buckle cable
(Chapter 3.28).
