Hardware Pack Parts List for Model CGI07ALP
* Two Batteries/AA included in the Hardware Pack.
PART # PART DESCRIPTION QTYPURPOSE OF PART
P06024005A Hardware Pack 1 For use in assembly (Grill and Range)
S112G04061 Phillips Head Screw 1/4"x3/8" 8 Install Cart Frames to Left / Right Bowl Panels
S162M04201 Hex Head Screw M4X20mm 2 Secure Faucet Washer and Faucet Bracket to Faucet
S233G03194 Wing Bolt 3/16"x1-3/16" 1 Secures Gas Tank to Tank Holder
P05515017L Wrench
1
Adjust level on Island Assembly Set
Already packed in the Faucet Assembly Kit Box
Already Installed on Tank Holder
Already packed in the Cooking Components Box
Phillips Head Screw 1/4"x3/8"
Qty. 8
Part # S112G04061
Wing Bolt 3/16"x1-3/16"
Qty. 1
Part # S233G03194
Hardware already installed on the Tank Holder
Hex Head Screw M4x20mm
Qty.2
Part # S162M04201
Already packed in the Faucet Assembly Kit Box
Wrench
Qty.1
Part # P05515017L
Already packed in the Cooking Components Box
