UCM630X Series User Manual
Version 1.0.2.25
Line and TO header in the SIP request to indicate the E.164 number. If set to
"Enable", "Tel:" will be used instead of "SIP:" in the SIP request. The default setting
is disabled.
Need Registration
Select whether the trunk needs to register on the external server or not when
"Register SIP Trunk" type is selected. The default setting is No.
Allow outgoing calls
if registration failure
If enabled outgoing calls even if the registration to this trunk fail will still be able to
go through.
Note that if we uncheck “Need Registration” option, this option will be ignored.
CallerID Name
Configure the new name of the caller when the extension has no CallerID Name
configured.
From Domain
Configure the actual domain name where the extension comes from. This can be
used to override the “From” Header.
For example, "trunk.UCM630X.provider.com" is the From Domain in From Header:
sip:1234567@trunk.UCM630X.provider.com.
From User
Configure the actual username of the extension. This can be used to override the
“From” Header. There are cases where there is a single ID for registration (single
trunk) with multiple DIDs.
For example, "1234567" is the From User in From Header:
sip:1234567@trunk.UCM630X.provider.com.
Username
Enter the username to register to the trunk from the provider when "Register SIP
Trunk" type is selected.
Password
Enter the password to register to the trunk when "Register SIP Trunk" is selected.
Auth ID
Enter the Authentication ID for "Register SIP Trunk" type.
Auth Trunk
If enabled, the UCM will send 401 response to the incoming call to authenticate
the trunk.
Auto Record
Enable automatic recording for the calls using this trunk (for SIP trunk only). The
default setting is disabled. The recording files can be accessed under Web
GUICDRRecording Files.
Direct Callback
Allows external numbers the option to get directed to the extension that last called
them.
For Example: User 2002 has dialed external number 061234575 but they were not
reachable, once they have received missed call notification on their phone, they
would mostly call back the number, if the option “Direct Callback” is enabled then
they will be directly bridged to user 2002 regardless of the configured inbound
destination.
Advanced Settings
Codec Preference
Select audio and video codec for the VoIP trunk. The available codecs are: PCMU,
PCMA, GSM, AAL2-G.726-32, G.726, G.722, G.729, G.723, iLBC, ADPCM,
H.264, H.265, H.263, H.263p and VP8.
