8
2.2 Buttons and Switches of Grand Ultimate 2000
l TV system switch
Selects the desired video standard output.
NOTE: In the United States, switch 1,2 and three should be ON and
switch four should be OFF.
Switch Switch Television
Standard
1 2 3 4
NTSC (USA) ON ON ON OFF
NTSC-EIA OFF ON ON OFF
PAL-M ON OFF ON OFF
PAL-N ON ON OFF OFF
PAL-B/D/G/H/I OFF ON OFF OFF
PAL-Combination N OFF OFF OFF OFF
RGB OUT enable ON
l SIZE button
Switch between UNDERSCAN and OVERSCAN. This function is
available on 640x480 mode only. Pressing this button also RESETS
the display to default position.
l ZOOM button
Toggles between ZOOM and NORMAL display.
l POSITION button
Press up, down, left and right buttons and the picture will move in the
direction pressed.
