Grant SQ2010 User Manual

18108 Version 15 SQ2020/40
Page 7
www.grant.co.uk
3
2
1
Wi-fi
Before using the Wi-fi connection it is necessary to assemble the antenna to the logger as
shown below.
1. Screw the antenna onto the threaded socket and orient it in the same direction as
the antenna on the receiver connected to the PC (usually vertical).
2. Attach an external power supply to the logger.
3. Turning on the power will cause the yellow and green lights on the module to start
flashing. A connection has been established when the yellow light stays on
permanently.
Wi-fi is only available when the logger is connected to an external power supply.
To complete the installation please refer to the configuration manual which can be found
under ‘~\SquirrelView\Manuals\SQ20xx Inbuilt Ethernet Configuration.pdf’ where
‘~\SquirrelView’ is the installation directory of SquirrelView.
