GRAPH TECH GHOST User Manual

2
3
Parts List
Set of GHOST-equipped saddles
Common connector block
Part number BE-5017-00
Dual Connector Teon Cable Assembly
Part number BE-5021-00
GHOST Acousti-Phonic Intelligent Pre-Amp
Passive Volume Kit
Stereo Jack
Volume potentiometer (pot), 5 Mega Ohm
Resistor, 5 Mega Ohm
Teon Cable
330pf Capacitor
Acousti-Phonic Intelligent GuitarPre-amp
Part number PE-0210-00, or
Acousti-Phonic Intelligent Bass Pre-amp
Part number PE-0310-00
Stereo Switched Jack
Part number PE-0216-00
Battery Snap Cable Assembly
Part number BE-0204-00
Part number BE-0205-00 (Clip)
Connector Cable Assemblies
Part number BE-5002-00 Six-Pin
Part number BE-5003-00 Six-Pin
GHOST Pickup System
•
•
•
•
•
•
•
•
•
•
•
•
•
x 6
x 1
x 1
QSW
PIN
MID
FA
A
S
VOL
MAG
RING
TIP
SW
PWR
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
Part number PE-0400-00 includes:
x 1
(PURPLE, YELLOW, GREEN & BLACK LEAD)
(RED, WHITE, BLUE & BLACK LEAD)
BLACK (E), BLUE (B), GREEN (G), YELLOW (D), RED (A) & WHITE (E) LEADS.
x 1
