MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
Hex key - 1 pce1.
Dust extraction stub pipe - 1 pce2.
Transport case - 1 pce3.
PREPARATION FOR OPERATION
BLADE INSTALLATION
Disconnect the power tool from power supply.
Use the hex key to loosen screws that x the blade shaft ( ● g. A).
Slide blade into clamp, push to the limit ●
Blade’s teeth should point forward. ●
Tighten the screws with the hex key ( ● g. A).
Ensure the blade is properly tted in the guide roller (10) (g. A).
Blade removal is similar to installation, only the sequence of actions is reversed.
Use blades shown on g. F, suitable for clamp mechanism.
DUST EXTRACTION
To improve dust extraction from processed surface the jigsaw is equipped with own dust blow-o system,
which cleans the surface being cut. Additionally, there is possibility to connect vacuum cleaner to dust
extraction stub pipe (4). Dust blow-o and extraction system is more ecient when the jigsaw guard is
lowered.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Before connecting the jigsaw to a power supply always check that power supply voltage matches
rated voltage on the rating plate xed on the power tool.
Switching on – press the switch button (2) and hold in this position (g. B).
Switching o – release pressure on the switch button (2).
Locking the switch (continuous operation)
Switching on:
Press the switch button ( ● 2) and hold in this position.
Press the switch lock button ( ● 3) (g. B).
Release pressure on the switch ( ● 2).
Switching o:
Press and release the switch ( ● 2).
CONTROL OF JIGSAW OPERATING SPEED
You can control rotational speed of jigsaw motor by turning and setting the wheel for operation speed
control (1) in desired position. It allows to adjust the power tool working speed to match characteristics of
processed material. Speed control ranges from 1 to 6.
The bigger the number on the wheel rim (1) (g. C), the greater the jigsaw operation speed.
