GRASS VALLEY +LDX5660 - Page 18

3922 407 63411 - ADAPTER BACK PANEL ASSY
List of Field Replacable Units (FRUs):
Pos Part Number Description Quantity
781 4-000000023-00
FRU kit PAN CAP SCR STL.ST M3x10 10
782 4-000000024-00 FRU kit PAN CAP SCR STL.ST M3x12 200
792 4-000000021-00 FRU kit COMBI SCR PAN STL ST M3X8
200
U1 3922 406 56911
PCBA BACKPANEL AUDIO
U2 3922 406 56871 PCBA POWER CONNECTOR BRD
U3 3922 406 56881 PCBA AUX CONNECTOR BRD
4-000000013-00 FRU kit LDX dustcovers adapter
Parts cannot be ordered separately
11 3922 400 11973 BNC CAP
1
3922 400 11982 RJ45 CAP
1
9 3922 400 11992 XLR FEM CAP 1
10 3922 400 12002 XLR MALE CAP
1
12 3922 400 12012 AUX CAP 1
516-00001-02 BNC CAP 1
4-000000007-00 FRU kit CLB FLEX
Parts cannot be ordered separately
2422 015 18546 CLB FLEX 30P FFC 0.5 SUMICARD TL=81MM 30V 5
3922 205 00005 CLB FLEX 10P FFC 0.5 SUMICARD TL=46MM 30V 5
2422 015 19425 CLB FLEX 10P FFC 0.5 SUMICARD TL=138MM 30V 5
2422 015 18547 CLB FLEX 10P FFC 0.5 SUMICARD TL=78MM 30V 5
3922 205 00123 CLB FLEX 30P FFC 0.5 SUMICARD TL=160MM 30V 5
81 3922 205 00006 CLB FLEX 30P FFC 0.5 SUMICARD TL=56MM 30V 5
2422 015 19905 CLB FLEX 30P FFC 0.5 SUMICARD TL=131MM 30V 5
↓
FRU kit contains
↓
FRU kit contains
