GRAULE ZS 170 - Producer Information; Technical Specifications

Graule Maschinenbau GmbH , Robert-Bosch-Str. 7, D-73431 Aalen
Tel: 0049 (0)7361 49511 Fax: 0049 (0)7361 49521, e-mail:info@graule.de
1.
1.1 Producer
GRAULE - Maschinenbau GmbH Robert Bosch Str. 7
D-73431 Aalen
Phone: 0049 – 7361 - 49511
Fax: 0049 – 7361 – 49521
e-mail:
info@graule.de
1.2 Technical dates
for Radial Arm Saw typ ZS 135 / ZS 170
sawblade diameter 350 / 420 mm
bore 30/40 / 40 mm
cutting range :
cross-cut 90° 430 / 410 mm
mitre cut 45° 300 / 290 mm
cutting height at 90° 135 / 170 mm
mitre range horizontal 45° - 90° - 25°
dust tube diameter 95 mm
weight 100 / 110 kg
motor 3 phases 380-400 Volt , 50 Hz , 2 kW
revolutions 3800 / 3500 rpm
1.3 Noise coefficient ( DIN 45635)
for Radial Arm Saw typ ZS 135 / ZS 170
Schalleistungspegel:
idle motion 95,7 / 100,3 dB(A)
in works 95,4 / 98,6 dB(A)
Arbeitsplatzbezogener Emissionswert:
idle motion 81,8 / 87,5 dB(A)
in works 82,3 / 84,5 dB(A)
2. Standart delivery
Radial Arm Saw without saw blade and without stand
wrench no.17 for changing saw blade
distance ring 30/40 mm at typ ZS 135
extra insert for wooden table
3. Accessories ( option )
for Radial Arm Saw typ ZS 135:
tct saw blade for wood 350 x 4,0 x 40 mm 42 t neg.
tct saw blade for wood 350 x 3,2 x 40 mm 72 t neg.
tct saw blade for upvc and aluminium 350 x 3,5 x 40 mm 108 t neg.
for Radial Arm Saw type ZS 170:
tct saw blade for wood 420 x 4,0 x 40 mm 48 t neg.
tct saw blade for upvc and aluminium 420 x 3,5 x 40 mm 100 t neg.
for both machine types:
stronger motor 3 kW
stand
hydraulic feed control ( hydro check cylinder )
pneumatic spray attachment
pneumatic clamp set
manuel clamp for left hand side
roller guide 300 mm wide, 2 mtr., 3 mtr. oder 4 mtr. long
roller guide including scale and length stop 300 mm widet, 2 mtr., 3 mtr. oder 4 mtr. long
extra fence for cutting small angles
digital read out for the angles
4. Safety devices
With locking device, below the operational grip, block the tool slide into its rear
