9
Nr. / No. Deutsch English Francais
1 E-Motor Electric motor Moteur électrique
2 Kupplung Coupling Accouplement
3 Klemmschraube Clamping screw Vis de serrage
4 Flexwelle Flexi-shaft Arbre exible
5 Seitliche Flexführung Lateral exi-shaft guide Guide latéral du exible
6 Wellenlagerung Shaft bearing Palier d´arbre
Graupner/SJ GTX 500 Version 2
