1. Pease screw the suction head into the bottom of the telescopic (fig.A)
2. Unscrew the battery cap(6) and take out the battery holder(5)[fig.B], insert 8
Alkaline batteries(not included) into the battery holder(5)[fig.C].
Note: The positive and negative terminals of the battery should be
installed correctly, otherwise, the product will not function[fig.D].
3. Press button “I” [fig.E],the unit will start working.
4. If using the telescopic poles, simply unscrew the knob on the surface countercloc-
kwise, adjust the length as required[fig. F] ,the total length can reach 190CM after
extension[fig. G].
Note: should not stretch the telescopic pole forcely , it may result in the pole coming
off.
5. How to clean the cleaner
(1) Turn off the switch and press the button on the main body, take the suction head
apart as indicted [fig.H].
(2) Remove the filter and take out the rubbish, then clean the filter [fig.I]. (3) Reinstall
