GREAT VIGOR LEOPARD - Page 13

28
XV3731
Battery Holder
28B
MV120
XV3731
28D
28D
28A -- Machine Screw 2x8mm -- 2
28B -- Machine Screw 2x15mm -- 1
28C -- Button Head Screw w/Glue 3x8mm -- 3
28D -- Tapping Screw 3x10mm -- 6
28E -- Post 6x32mm -- 3
CH2
Throttle
28D
28C
28A
28D
28C
MV308
MV310
MV308
Switch
MV308
Finished
29
29A
Step28
Finished
Step27
29A -- Tapping Screw 3x10mm -- 1
XV3731
