GREAT VIGOR LEOPARD - Page 15

33
33A -- Lock Nut 3mm -- 2
33B -- Shim 6.1x9.8x0.2mm -- 2
33C -- Cap Screw 3x18mm -- 2
33D -- Washer-Head Screw w/Glue 4x10mm -- 2
Step30
33A
33D
33D
Step25
33B
33A
33B
Step32
Step30
33C
33C
34
34C
Step24
34A
Step33
34C
34B
34D
34A -- Flanged Lock Nut 3mm -- 1
34B -- F/H Screw w/Glue 4x10mm -- 2
34C -- Cap Screw 3x16mm -- 2
34D -- F/H Screw 3x20mm -- 1
