GREAT VIGOR LEOPARD - Page 4

5
5B
MV107Ti
5E
5D
MV134
5E
For Right Side
MV3531
R
MV3481
MV3576
5F
MV3531
5F
5A
5C
5A
MV3574
5A -- Grub Screw 4x3mm -- 4
5B -- Grub Screw w/Glue 5x5mm -- 2
5C -- Pin 2.5x13.8mm -- 2
5D -- Pin 2.5x16.8mm -- 2
5E -- Ball Bearing 8x16x5mm -- 4
5F -- Cap Screw w/Glue 4x12mm -- 4
For Left Side
MV3481
L
6
For Right Side and Left Side x2
6A
MV349F2
MV349F2
10.5mm
6A -- Turnbuckle 5x25mm -- 2
7B -- Hub Stud 3x37.5mm -- 4
7A -- Lock Nut 3mm -- 4
MV347F2
7B
7A
Step5
7B
7
7A
Step6
For Right Side
Finished
For Left Side
