Gree GUD35P/A-T User Manual

DC Inverter U-match Series Duct Type Unit
40
contact Gree’s local service center.
⑩. Wiring terminals should be connected firmly to the terminal board. Loose
connection is forbidden.
⑪. After the electrical installation is finished, please use wire clamps to secure the
power cord, connection wire of indoor and outdoor units and the
communication cords. Make sure the wires are not clamped too tight.
⑫. The wire gauge of power cord should be large enough. Damaged power cord
or other wires must be replaced by specialized wires. Wiring work must be
done according to national wiring rules and regulations.
3.3.2 Electrical Parameters
3.3.2.1 Wire Specifications and Fuse Capacity
Model
Power supply
Fuse
capacity
Circuit breaker
capacity
Min. sectional area
of power cord
V/Ph/Hz
A
A
mm
2
Indoor
unit
220V-240V ~50Hz
208V-230V ~60Hz
3.15
6
1.0
Model
Power supply
Circuit
breaker
capacity
Min. sectional
area of power
cord
V/Ph/Hz
A
mm
2
GUD35W/NhA-T
220V-240V ~50Hz
208V-230V ~60Hz
16
1.5
GUD50W/NhA-T
16
1.5
GUD71W/NhA-T
20
2.5
GUD85W/NhA-T
25
2.5
GUD100W/NhA-T
32
4.0
GUD125W/NhA-T
32
4.0
GUD140W/NhA-T
40
6.0
GUD100W/NhA-X
380V-415V 3N~50Hz/60Hz
16
1.5
GUD125W/NhA-X
16
1.5
GUD140W/NhA-X
16
1.5
GUD160W/NhA-X
16
1.5
NOTICE:
①. Fuse is located on the main board.
②. Install a circuit breaker at every power terminal near the units (indoor and

Gree GUD35P/A-T Specifications

General

Brand	Gree
Model	GUD35P/A-T
Category	Air Conditioner
Language	English
