11
Technical Information
Service Manual
Model GWC09ATCXB-D3DNA1A GWH09ATCXB-D3DNA1A
Product Code CB574001000 CB574000900
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9100 9100
Heating Capacity Btu/h / 10000
Cooling Power Input W 805 805
Heating Power Input W / 781
Cooling Current A 3.75 3.75
Heating Current A / 3.9
Rated Input W 1350 1450
Rated Current A 6.5 6.5
EER (Btu/h)/W 11.30 11.30
COP (Btu/h)/W / 12.80
SEER 19.5(SEER)/19.5(SEER2) 19.5(SEER)/19.5(SEER2)
HSPF / 10(HSPF)8.8(HSPF2)
Air Flow Volume CFM 353/282/264/229/211/194/158 353/282/264/229/211/194/158
Dehumidifying Volume Pint/d 1.69 1.69
Application Area yd
2
14-22 14-22
Indoor Unit
Indoor Unit Model GWC09ATCXB-D3DNA1A/I GWH09ATCXB-D3DNA1A/I
Product Code of Indoor Unit CB574N01000 CB574N00900
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф94X630 Ф94X630
Cooling Speed r/min 1350/1150/1100/1000/950/850/750 1350/1150/1100/1000/950/850/750
Heating Speed r/min / 1300/1100/1050/1000/950/850/800
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.30 0.30
Fan Motor Capacitor μF 1.5 1.5
Heater Power Input W / 72
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.3 2-1.3
Evaporator Coil Length (LXDXW) mm 634X22.8X266.7 634X22.8X266.7
Swing Motor Model MP24HF MP24HF
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 41/37/34/32/31/28/26
Cooling:41/37/34/32/31/28/26
Heating:41/36/34/32/31/28/26
Sound Power Level dB (A) 51/47/44/42/41/38/36
Cooling:51/47/44/42/41/38/36
Heating:51/46/44/42/41/38/36
Dimension (WXHXD) inch 32 7/8X10 53/64X7 7/8 32 7/8X10 53/64X7 7/8
Package Carton Dimension
(LXWXH)
inch 35 1/32X12 61/64X10 15/64 35 1/32X12 61/64X10 15/64
Package Dimension (LXWXH) inch 35 15/64X13 37/64X10 43/64 35 15/64X13 37/64X10 43/64
Net Weight Ib 19.8 19.8
Gross Weight Ib 24.3 24.3
