Gree GWC09QB-A3DNA5E User Manual

9
Technical Information
Service Manual
Model
GWC12QC-A3DNA5K
GWC12QC-A3DNB2K
GWC12QC-A3DND8K
GWH12QC-A3DNA5K
GWH12QC-A3DNB2K
GWH12QC-A3DNB8K
Product Code
CB425007800
CB432008900
CB459003900
CB425007900
CB432009100
CB438008200
Power Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 12000(3753~12500) 12000(3753~12500)
Heating Capacity(Min~Max) Btu/h / 13000(3412~15013)
Cooling Power Input(Min~Max) W 1155(380~1300) 1193(380~1300)
Heating Power Input(Min~Max) W / 1250(350~1350)
Cooling Power Current A 13.5 13.5
Heating Power Current A / 13.8
Rated Input W 1300 1350
Rated Current A 13.0 13.5
Air Flow Volume(SH/H/M/L) CFM 400/318/241/194 400/318/241/194
Dehumidifying Volume Pint/h 2.96 2.96
EER (Btu/h)/W 10.39 10.06
COP (Btu/h)/W / 10.40
SEER 16 16
HSPF / 9
Application Area yd
2
19.14-28.70 19.14-28.70
Indoor Unit
Model of indoor unit
GWC12QC-A3DNA5K/I
GWC12QC-A3DNB2K/I
GWC12QC-A3DND8K/I
GWH12QC-A3DNA5K/I
GWH12QC-A3DNB2K/I
GWH12QC-A3DNB8K/I
Indoor Unit Product Code
CB425N07800
CB432N08900
CB459N03900
CB425N07900
CB432N09100
CB438N08200
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 7/8X24 15/16 Φ3 7/8X24 15/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1000/800 1350/1200/1000/800
Fan Motor Heating Speed(SH/H/M/L) r/min / 1350/1200/1000/900
Output of Fan Motor W 20 20
Fan Motor RLA A 0.25 0.25
Fan Motor Capacitor μF 4 4
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16 Φ3/16
Row-n Gap inch 2-1/18 2-1/18
Coil Length (LXDXW) inch 25X7/8X12 1/16 25X7/8X12 1/16
Swing Motor Model MP24BA MP24BA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/39/35/29 43/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 53/49/45/39 53/49/45/39
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X10 15/16X14 5/16 36 1/8X10 15/16X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11 1/16X14 15/16 36 1/4X11 1/16X14 15/16
Net Weight Ib 23.15 23.15
Gross Weight Ib 27.56 27.56
