75
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWC12QC-A3DNA5K/I GWH12QC-A3DNA5K/I
Product Code CB425N07800 CB425N07900
1 Front Panel 2002269402S 2002269402S 1
2 Front Case 00000200022 00000200022 1
3 Axile Bush 10542036 10542036 1
4 Helicoid Tongue 26112436 26112436 1
5 Left Axile Bush 10512037 10512037 1
6 Display Board 30565260 30565260 1
7 Rear Case assy 00000100093 00000100093 1
8 Rubber Plug (Water Tray) 76712012 76712012 1
9 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
10 Ring of Bearing 26152022 26152022 1
11 Cold Plasma Generator / / /
12 Evaporator Assy 0100297601 0100297601 1
13 Wall Mounting Frame 01252484 01252484 1
14 Cross Flow Fan 10352056 10352056 1
15
Fan Motor 1501214605
1501214605
1
16
Connecting pipe clamp 2611216401
2611216401
1
17 Drainage Hose 05230014 05230014 1
18 Stepping Motor 1521210701 1521210701 1
19 Crank 73012005 73012005 1
20 Electric Box Assy 10000204467 10000204444 1
21 Terminal Board 42011233 42011233 1
22 Jumper 4202021906 4202021906 1
23 Main Board 300002000308 300002000307 1
24 Electric Box Cover Sub-Assy 0140206501 0140206501 1
25 Shield Cover of Electric Box Cover 01592150 01592150 1
26 Electric Box Cover 2011220701 2011220701 1
27 Power Cord / / /
28 Connecting Cable / / /
29 Evaporator Support 24212179 24212179 1
30 Remote Controller 30510475 30510475 1
31 Detecting plate(WIFI) 30070077 30070077 1
