82
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWC09QB-A3DNA6E/O GWC12QC-A3DNA6E/O
Product Code CB427W04000 CB427W03800
1 Front Grill 01473012 01473012 1
2 Cabinet 0143305801P 0143305801P 1
3 Axial Flow Fan 10333004 10333004 1
4 Fan Motor 1501308507 1501308507 1
5 Chassis Sub-assy 0120388106P 0120388104P 1
6 Compressor Gasket 76710302 76710302 3
7 Electrical Heater(Compressor) / / /
8 Compressor and ttings 00103862 00103862 1
9 Capillary Sub-assy 03000600471 03000600462 1
10 Valve cover 2012300101 2012300101 1
11 Valve 07100005 07100005 1
12 Valve 07130239 07130239 1
13 Valve Support 01713041 01713041 1
14 Cable Cross Plate sub-assy 02123015 02123015 1
15 Right Side Plate Assy 013030713 013030713 1
16 Cover of pass wire 01413069 01413069 1
17 Magnet Coil / / /
18 Discharge Tube Sub-assy 03001300334 03001300334 1
19 Inhalation Tube Sub-assy 03001000151 03001000151 1
20
Compressor Overload
Proctector(External)
00180030 00180030 1
00183031 00183031 1
00183032 00183032 1
21 Temperature Sensor 3900030805 3900030805 1
22 Rear Grill 01473057 01473057 1
23 Condenser Assy 01100200492 01100200481 1
24 Clapboard Sub-Assy 01233034 01233034 1
25 Top Cover Plate 01253443 01253443 1
26 Motor Suport 01703103 0170310401 1
27 Capacitor Box Sub-Assy 01403767 01403767 1
28 Terminal Board 42010255 42010255 1
29 Electric box 1 20113005 20113005 1
30 Main Board 30138000848 30138000864 1
31 Electric Box Assy 10000100608 10000100610 1
32 Electric Box Cover Sub-Assy 0260309601 0260309601 1
To Next Page
