GWH09QB-A3DNA6E/O GWH12QC-A3DNA6E/O
Product Code CB427W03900 CB427W03700
1 Front Grill 01473012 01473012 1
2 Cabinet 0143305801P 0143305801P 1
3 Electrical heater (Chassis) 76510010 76510010 1
4 Axial Flow Fan 10333004 10333004 1
5 Chassis Sub-assy 0120388105P 0120388103P 1
6 Compressor Gasket 76710302 76710302 3
7 Drainage Connecter 06123401 06123401 1
8 Overload Protector
00180030 00180030 1
00183031 00183031 1
00183032 00183032 1
9 Compressor and ttings 00103862 00103862 1
10 Electrical heater 76510010 76510010 1
11 Magnet Coil 4300040021 4300040021 1
12
4-Way Valve Assy 03073403
03073403
1
13 Right Side Plate Assy 013030713 013030713 1
14
Valve 07100005 07100005 1
15 Valve Support 01713041 01713041 1
16 Valve 07100003 07100003 1
17 Cable Cross Plate sub-assy 02123015 02123015 1
18 Cover of pass wire 01413069 01413069 1
19 Magnet Coil 4300040021 4300040021 1
20 Rear Grill 01473057 01473057 1
21 Condenser Assy 01100200497 01100200482 1
22 Temperature Sensor 3900030805 3900030805 1
23 Clapboard Sub-Assy 01233034 01233034 1
24 Top Cover Plate 01253443 01253443 1
25 Motor suport spot welding sub-assy 01703104 0170310401 1
26 Fan Motor 1501308507 1501308507 1
27 Capacitor Box Sub-Assy 01403767 01403767 1
28 Terminal Board 42010255 42010255 1
29 Electric box 1 20113005 20113005 1
30 Main Board 30138000865 30138000863 1
31 Electric Box Assy 10000100609 10000100611 1
32 Electric Box Cover Sub-Assy 0260309601 0260309601 1
33 Valve Cover 2012300101 2012300101 1
34 Capillary Sub-assy 03000600331 03000600463 1
