90
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH12QC-A3DNA5K/O GWH09QB-A3DNA5K/O
Product Code CB425W07900 CB425W08200
1 Front Grill 01473012 01473012 1
2 Cabinet 0143305801P 0143305801P 1
3 Electrical heater (Chassis) 76510010 76510010 1
4 Axial Flow Fan 10333004 10333004 1
5 Chassis Sub-assy 0120388103P 0120388105P 1
6 Compressor Gasket 76710302 76710302 3
7 Drainage Connecter 06123401 06123401 1
8 Overload Protector
00180030 / 1
00183031 / 1
00183032 / 1
9 Compressor and ttings 00103862 00103862 1
10 Electrical heater 76510010 76510010 1
11 Magnet Coil 4300040021 4300040021 1
12
4-Way Valve Assy 03073403
03073403
1
13 Right Side Plate Assy 013030713 013030713 1
14
Valve 07100005 07100005 1
15 Valve Support 01713041 01713041 1
16 Valve / 07100003 1
17 Cable Cross Plate sub-assy 02123015 02123015 1
18 Cover of pass wire 01413069 01413069 1
19 Magnet Coil 4300040021 4300040021 1
20 Rear Grill 01473057 01473057 1
21 Condenser Assy 011002000466 011002000509 1
22 Temperature Sensor 39000310 39000310 1
23 Clapboard Sub-Assy 01233034 01233034 1
24 Top Cover Plate 01253443 0125344311P 1
25 Motor suport spot welding sub-assy 0170310401 01703104 1
26 Fan Motor 1501308507 1501308507 1
27 Capacitor Box Sub-Assy 20113004 20113004 1
28 Terminal Board 42010255 42010255 1
29 Electric box 1 20113005 20113005 1
30 Main Board 300027000325 300027000356 1
31 Electric Box Assy 100002001751 100002001953 1
32 Electric Box Cover Sub-Assy 0260309601 0260309601 1
33 Valve Cover 2012300101 2012300101 1
34 Electric Expansion Valve Sub-Assy 030026000185 #N/A 1
To Next Page
