Installation and Maintenance

Service Manual

$ERYHGDWDLVVXEMHFWWRFKDQJHZLWKRXWQRWLFH

No.

Description

Part Code

Qty

GWC09QB-K3DNA1B/I

(cold plasma)

GWH09QB-K3DNA1B/I

(cold plasma)

GWH09QB-K3DNA1B/I

3URGXFW&RGH CB419N01600 CB419N01700 CB419N01701

1 )URQW3DQHO$VV\ 20022496 20022496 20022496 1

2 Display Board 30565231 30565231 30565231 1

3 )URQW&DVH$VV\ 20022495 20022495 20022495 1

4 +HOLFRLG7RQJXH 26112508 26112508 26112508 1

5 /HIW$[LOH%XVK 10512037 10512037 10512037 1

6 Rear Case assy 22202560 22202560 20162010 1

7 Drainage Hose 0523001408 0523001408 0523001408 1

8 Ring of Bearing 26152022 26152022 26152022 1

9 Cold Plasma Generator 1114001602 1114001602 / 1

10 (YDSRUDWRU$VV\ 01002954 01002954 01002954 1

11 :DOO0RXQWLQJ)UDPH 01252043 01252043 01252043 1

12 &URVV)ORZ)DQ 10352059 10352059 10352059 1

13 )DQ0RWRU 1501208904 1501208904 1501208904 1

14 Connecting pipe clamp 2611216401 2611216401 2611216401 1

15 5XEEHU3OXJ:DWHU7UD\ 76712012 76712012 76712012 1

16 Stepping Motor 1521212901 1521212901 1521212901 1

17 &UDQN 73012005 73012005 73012005 1

18 Electric Box Assy 20102000291 20402492 10000201755 1

19 $[LOH%XVK 10542036 10542036 10542036 1

20 Terminal Board 42011233 42011233 42011233 1

21 -XPSHU 4202300101 4202300101 4202300101 1

22 Main Board 30138000164 30148822 30148823 1

23 (OHFWULF%R[&RYHU 20112207 20112207 20112207 1

24 (OHFWULF%R[&RYHU6XE$VV\ 02601070 02601070 01402065 1

25 6KLHOG&RYHURI(OHFWULF%R[&RYHU 01592154 01592154 01592150 1

26 Power Cord 4002048710 4002048710 4002048712 1

27 Connecting Cable 400205235 400205235 40020538 0

28 Remote Controller 30510474 30510474 30510474 1
