Installation and Maintenance

Service Manual

$ERYHGDWDLVVXEMHFWWRFKDQJHZLWKRXWQRWLFH

No.

Description

Part Code

Qty

GWH12QC-K3DNA2B/I

(cold plasma)

GWH12QC-K3DNA5B/I

3URGXFW&RGH CB426N00800 CB425N00800

1 )URQW3DQHO$VV\ 20022704 00000300003 1

2 Display Board 30565265 30565231 1

3 )URQW&DVH$VV\ 20022731 00000200022 1

4 +HOLFRLG7RQJXH 26112507 26112507 1

5 /HIW$[LOH%XVK 10512037 10512037 1

6 Rear Case assy 22202375 22202375 1

7 Drainage Hose 05230014 05230014 1

8 Ring of Bearing 26152022 26152022 1

9 (YDSRUDWRU6XSSHU 24212174 24212179 1

10 Cold Plasma Generator 1114001602 / 1

11 (YDSRUDWRU$VV\ 01002000030 01002000030 1

12 :DOO0RXQWLQJ)UDPH 01252484 01252484 1

13 &URVV)ORZ)DQ 10352056 10352056 1

14 )DQ0RWRU 15012146 15012146 1

15 Connecting pipe clamp 2611216401 2611216401 1

16 5XEEHU3OXJ:DWHU7UD\ 76712012 76712012 1

17 Stepping Motor 1521210701 1521210701 1

18 &UDQN 73012005 73012005 1

19 Electric Box Assy 10000200552 10000200847 1

20 $[LOH%XVK 10542036 10542036 1

21 Terminal Board 42011233 42011233 1

22 -XPSHU 4202300114 4202300105 1

23 Main Board 30148827 30148824 1

24 (OHFWULF%R[&RYHU6XE$VV\ 01402065 01402065 1

25 6KLHOG&RYHURI(OHFWULF%R[&RYHU 01592150 01592150 1

26 (OHFWULF%R[&RYHU 20112207 20112207 1

27 Power Cord 4002048712 4002048712 1

28 Connecting Cable 40020538 40020538 0

29 Remote Controller 30510474 30510474 1
