Technical Information
Service Manual
Model
GWH09QB-A3DNA5E
GWH09QB-A3DNC2E
GWH09QB-A3DNB8E
GWH09QB-A3DNB2E
Product Code
CB425006400
CB439006001
CB438003702
CB432006002
Power Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(2764~10918) 9000(2764~10918)
Heating Capacity(Min~Max) Btu/h 9600(2081~12263) 9600(2081~12263)
Cooling Power Input(Min~Max) W 895(350~1270) 895(350~1270)
Heating Power Input(Min~Max) W 852(280~1250) 852(280~1250)
Cooling Power Current A 10.93 10.93
Heating Power Current A 10.20 10.20
Rated Input W 1270 1270
Rated Current A 11.27 11.27
Air Flow Volume(SH/H/M/L) CFM 318/288/241/171 318/288/241/171
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 10.06 10.06
COP (Btu/h)/W 11.25 11.25
SEER 16.00 16.00
HSPF 9.00 9.00
Application Area yd
2
14.35-21.53 14.35-21.53
Indoor Unit
Model of indoor unit
GWH09QB-A3DNA5E/I
GWH09QB-A3DNC2E/I
GWH09QB-A3DNB8E/I
GWH09QB-A3DNB2E/I
Indoor Unit Product Code
CB425N06400
CB439N06001
CB438N03702
CB432N06002
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 7/8X22 13/16 Φ3 7/8X22 13/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750 1350/1200/1050/750
Fan Motor Heating Speed(SH/H/M/L) r/min 1350/1200/1050/850 1350/1200/1050/850
Output of Fan Motor W 20 20
Fan Motor RLA A 0.24 0.24
Fan Motor Capacitor μF 4 4
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16 Φ3/16
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 23X7/8X10 8/16 23X7/8X10 8/16
Swing Motor Model MP24AA MP24AA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 42/38/34/28 42/38/34/28
Sound Power Level(SH/H/M/L) dB (A) 52/49/45/39 52/49/45/39
Dimension (WXHXD) inch 31 1/8X10 13/16X7 7/8 31 1/8X10 13/16X7 7/8
Dimension of Carton Box (LXWXH) inch 34X10 9/16X13 7/8 34X10 9/16X13 7/8
Dimension of Package (LXWXH) inch 34 1/8X10 11/16X14 7/16 34 1/8X10 11/16X14 7/16
Net Weight Ib 20.94 19.84
Gross Weight Ib 25.35 24.25
