84
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWC12QC-D3DNA6H/O
Product Code CB427W05800
1 Front Grill 01473012 1
2 Front Panel Assy 0153304804 1
3 Axial Flow Fan 10333004 1
4 Fan Motor 1501306723 1
5 Chassis Sub-assy 017000000057P 1
6 Compressor Gasket 76710287 3
7 Compressor and ttings 00103364 1
8 Valve Support 0171314201P 1
9 Cut off Valve Assy 07133474 1
10 Valve Support Block 26113017 2
11 Valve 07133082 1
12 Cable Cross Plate 2 02123014P 1
13 Right Side Plate Assy 013030713 1
14 Cover of pass wire 01413069 1
15 Inhalation Tube Sub-assy 030010000181 1
16 Discharge Tube 035008000337 1
17 Temperature Sensor 3900030805 1
18 Capillary Sub-assy 030006000137 1
19 Rear Grill 01473009 1
20 Condenser Assy 011002000133 1
21 Clapboard Sub-Assy 0123338502 1
22 Top Cover Sub-Assy 01253073 1
23 Motor Support 0170310401 1
24 Electric Box Assy 10000100886 1
25 Reactor 43130184 1
26 Electric Box Cover Sub-Assy 10000500541 1
27 Main Board 30138001267 1
28 Terminal Board 42010313 1
29 Wire Clamp 71010003 1
30 valve cover 2012300101 1
To Next Page
