59
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGWC18QD-D3DNA6E/I GWC18QD-D3DNB4E/I
Product Code CB427N01700 CB434N01500
1 Front Panel 2002269501S 20000300028 1
2 Filter Sub-Assy 11122089 11122089 2
3 Decoration board(left and right) 2019267001 / 1
4 Front Case 2002248401 2002248401 1
5 Guide Louver 1051276501 1051276501 1
6 Axile Bush 10542036 10542036 2
7 Air Louver(Manual) 10512732 10512732 3
8 Helicoid Tongue 26112512 26112512 1
9 Left Axile Bush 10512037 10512037 1
10 Display Board 30565264 30565260 1
11 Rear Case assy 22202571 22202571 1
12 Rubber Plug (Water Tray) 76712012 76712012 1
13 O-Gasket sub-assy of Bearing 7651205102 7651205102 1
14 O-Gasket of Cross Fan Bearing 76512203 76512203 1
15 Evaporator Support 24212177 24212177 1
16 Evaporator Assy 0100200001401 0100200001401 1
17 Cross Flow Fan 10352060 10352060 1
18 Fan Motor 1501214503 1501214503 1
19 Motor Press Plate 26112511 26112511 1
20 Wall Mounting Frame 01362026 01362026 1
21 Connecting pipe clamp 2611218801 2611218801 1
22 Crank 73012005 73012005 1
23 Stepping Motor 1521240212 1521240212 1
24 Drainage Hose 05230014 05230014 1
25 Electric Box Assy 10000201660 10000202358 1
26 Lower Shield of Electric Box 01592139 01592139 1
27 Electric Box 2011221102 2011221102 1
28 Jumper 4202021919 / 1
29 Main Board 30138000657 30138000657 1
30 Terminal Board 4201123303 4201123303 1
31 Electric Box Cover 2011220901 2011220901 1
32 Shield Cover of Electric Box 01592140 01592140 1
33 Screw Cover 2425201726 2425201726 3
34 Electric Box Cover2 2011221001 2011221001 1
35 Power Cord / / /
36 Connecting Cable / / /
37 Remote Controller 30510475 30510475 1
38 Cold Plasma Generator / / /
To Next Page
